NEW Orion HCCA3000.1D-SPLX 3000W RMS at 1 Ohm Car Audio Mono Subwoofer Amplifier
Product details
| Management number | 238325726 | Release Date | 2026/07/11 | List Price | US$319.98 | Model Number | 238325726 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
In the 1980's, the technology was transistors and massive class AB designs that stretched the length of a football field, today it's more efficient MOSFET class D designs, but the outcome is still the same: serious amounts of power driving ridiculously low impedance's at completely sick output levels. Whether you're looking for an SPL world record or you just want to do some serious damage on the streets, these amplifiers wil ensure they hear you before they see you. Hellacious power intersects with extreme efficiency under rugged die-cast aluminum covers with illuminated ORION badges that tell the world that HCCA is back! HCCA3000.1D-SPLX Class D Mono Subwoofer Car Audio Amplifier
- RMS WATTS@ 4 OHM MONO @ 0.5% THD+N 1350W
- RMS WATTS@ 2 OHM MONO @ 0.5% THD+N 2100W
- RMS WATTS@ 1 OHM MONO @ 0.5% THD+N 3000W
- Amplifier Efficiency > 88%
- Signal to Noise ratio at rated output power and lowest impedance >90dB
- Remote Gain Function Yes
- Distortion at Rated Power 0.5% THD+N
- Frequency Response 15 Hz to 250Hz +/- 2.5 dB linear Bandwidth 15 Hz to 250Hz +/- 3 dB
- Damping Factor 200 Input Sensitivity(rms) 200mV to 8V
- Supply Voltage Range 9 to 16V
- Protection thermal, DC offset, short protection, undervoltage, over-voltage
- Wire Gauge Power AWG "O" X 3PCS Re mote AWG 10 Ground AWG "O" X 3PCS
- Speaker AWG 4
- Input Impedance 24kΩ
- Balanced input (CMRR) Yes
- Crossover Section Low Pass Crossover Continuously variable (40-300Hz)
- Phase shift control 0⁰ to 180⁰ Bass Boost 0-18dB
- variable Infrasonic(sub sonic) Filter Selectable On/Off Octave 12dB at 25Hz
- Length(in/cm): 18.9" / 48.0cm
- Height(in/cm): 3.0" / 7.7cm
- Depth(in/cm): 11.8" / 30.2cm
| Brand | Orion |
|---|---|
| Rms power rating | 3000 W |
| Channels | 1 |
| Impedance | 1 ohm |
| Peak audio power handling | 9000 W |
| Rec. use | Car Audio |
| Size | 14" x 12" x 4" |
| Color | red |
| Audio output | 3000 W |
| Total harmonic distortion | 0.5 % |
| Signal-to-noise ratio | 90 dB |
| Input/output direction | Input |
| Model | HCCA3000.1D-SPLX |
| Vehicle type | Car |
| Has written warranty | No |
| Assembled product weight | 28 lb |
| Volts | 12 V |
